Basic Electronic Engineering

Which current is generated due to shorting of gate terminal to source with zero value of gate-to-source voltage?

Zero-source voltage drain current

Zero-drain voltage gate current

Zero-source voltage gate current

Zero-gate voltage drain current

Which type of static characteristics exhibit the relationship between drain current and gate-to-source voltage for several values of drain-to-source voltage?

Drain characteristics

Transfer characteristics

Both a & b

None of the above

Match the following FET behavior with respective Drain Characteristic Regions: 1. Resistor -------------------------------------------- A) Breakdown Region 2. Constant-Current Source ------------------ B) Ohmic Region 3. Constant-Voltage Source ------------------ C) Pinch-off Region

1-A, 2-C, 3-B

1-C, 2-B, 3-A

1-A, 2-B, 3-C

1-B, 2-C, 3-A

The rectified & filtered signal taken at a high level point in AGC amplifier generates _______.

Dc voltage proportional to the level of an output signal

Dc voltage proportional to the level of an input signal

Ac voltage proportional to the level of output signal

Ac voltage proportional to the level of an input signal

The enhancement type basically termed as normally-OFF MOSFET works only with _______.

large positive gate voltage

Large negative gate voltage

large positive drain voltage

Large negative drain voltage
